SP4 Error in calculation of the relative eccentricity of journal bearing (angular span 180°) according DIN 31652 The iteration to get the relative eccentricity according the standard DIN 31652 was wrong for a journal bearing with an angular span of 180°.
KISSsoft - Bearing calculation SP4 Legend not shown for subsurface stress In the graph of the subsurface stress of the inner geometry bearing (W051) and shaft (W010) module, the legend was not shown when activated. SP5 FEM-Root stress: Gear selection for 3- and 4-gear chains and planetary systems The information on the gear that was selected to be analyzed was not passed correctly to the calculation, for the cases of 3- and 4-gear chains and planetary systems. This affected also the singular tooth stiffness reported from the FEM root stress calculation.
KISSsoft - Root stress FEM calculation SP5 FEM root stress: Tooth bending of internal gears The amount of tooth bending of internal gears was not calculated correctly. This is now fixed, additional message is displayed in the report. SP5 Applying tip rounding in the normal section In some gears with high helix angle (crossed helical gears, cylindrical gears), the tip form diameter was not calculated correctly.
